Unit conversion and data
Thread Size
Pitch
T.P.I
Head
Height
Head
Diameter
Socket A/F
Socket
Depth
Min T.L
M3
0.5
2.3
5.5
2
2
18
M4
0.7
2.8
7
2.5
2.3
20
M5
0.8
3.5
8.5
3
2.7
22
M6
1
4
10
4
3
24
M8
1.25
5
13
5
4.2
28
M10
1.5
6
16
7
4.8
32
M12
1.75
7
18
8
5.3
36
M14
2
8
21
10
5.5
40
M16
2
9
24
12
5.5
44
M18
2.5
10
27
12
7.5
48
M20
2.5
11
30
14
7.5
52
M22
2.5
12
33
14
8
56
M24
3
13
36
17
8
6

                            actual         max            max                  nom             min             min


Metric Low Head Cap Screw - DIN 7984
These dimensions are
For guidance only
