Unit conversion and data
Thread Size
Pitch
T.P.I
Head
Height
Head
Diameter
Socket A/F
Socket
Depth
Min T.L
M1.6
0.35
1.6
3
1.5
0.7
15
M2
0.4
2
3.8
1.5
1
16
M2.5
0.45
2.5
4.5
2
1.1
17
M3
0.5
3
5.5
2.5
1.3
18
M4
0.7
4
7
3
2
20
M5
0.8
5
8.5
4
2.5
22
M6
1
6
10
5
3
24
M8
1.25
8
13
6
4
28
M10
1.5
10
16
8
5
32
M12
1.75
12
18
10
6
36
M14
2
14
21
12
7
4
M16
2
16
24
14
8
44
M20
2.5
20
30
17
10
52
M24
3
24
36
19
12
60
M30
3.5
30
45
22
15.5
72
M36
4
36
54
27
19
84
M42
4.5
42
63
32
24
96
M48
5
48
72
36
28
108
M56
5.5
56
84
41
34
124
M64
6
64
96
46
38
140

                            actual         max            max                  nom             min             min


Socket Cap Screws Metric
These dimensions are
For guidance only
