Unit conversion and data
THREAD
SIZE
PITCH
T.P.I
HEX
FLAT
Hex
corners
Head
Height
Shank
Dia min
Bolt
T.L
M1.6
0.35
3.2
3.7
1.23
1.46
10
M2
0.4
4
4.6
1.53
1.86
10
M2.5
0.45
5
5.8
1.83
2.36
11
M3
0.5
5.5
6.4
2.13
2.86
12
M4
0.7
7
8.1
2.93
3.82
14
M5
0.8
8
9.2
3.65
4.82
16
M6
1
10
11.5
4.15
5.82
18
M7
1
11
12.7
4.9
6.82
20
M8
1.25
13
15
5.65
7.78
22
M10
1.5
17
19.6
7.18
9.78
26
M12
1.75
19
21.9
8.18
11.73
30
M14
2
22
25.4
9.18
13.73
34
M16
2
24
27.7
10.18
15.73
38
M18
2.5
27
31.2
12.22
17.73
42
M20
2.5
30
34.6
13.22
19.67
46
M22
2.5
32
36.9
14.22
21.67
50
M24
3
36
41.6
15.22
23.67
54
M27
3
41
47.3
17.22
26.67
60
M30
3.5
46
53.1
19.26
29.67
66
M33
3.5
50
57.7
21.26
32.61
72
M36
4
55
63.5
23.26
35.61
78
M39
4
60
69.3
25.26
38.61
84
M42
4.5
65
75
26.26
41.61
90
M48
5
75
86.6
30.26
47.61
102
M56
5.5
85
98.1
35.31
55.61
118
M64
6
95
109.7
40.31
63.61
134

                            actual         nom             max                max              min             min


Hex head Bolts and Setscrews Metric BS3692
Lengths 125mm to 200mm add 6mm to T.L,  and exceeding 200mm add 19mm to T.L
These dimensions are
For guidance only
